Pre Treatment Self Cleaning Filtration For Producing Purified Water ISO9001 Manganese Sand Filter

Place of Origin Tai'an, Shandong
Brand Name Tonglida
Certification ISO9001 Quality System Certification
Model Number 1T/H-100T/H
Minimum Order Quantity 1 unit
Delivery Time As per requirements

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Features Pre-treatment For Producing Purified Water, Boiler Feedwater, Industrial Process Water, And Drinking Water. Purpose Production Of Purified Water, Boiler Feedwater, Industrial Process Water, And Drinking Water Filtration System
Material Stainless Steel, Carbon Steel, Fiberglass Brand Tonglida
Product Information Quartz Sand Filtration, Activated Carbon Filtration, Manganese Sand Filter, Shallow Bed Sand Filtration, Self-cleaning Filtration, Precision Filtration
High Light

iso9001 manganese sand filter

,

pre treatment self cleaning filtration

,

iso9001 self cleaning filtration
Leave a Message
Product Description





Product Description:

The filtration system is composed of several filters such as quartz sand filter, activated carbon filter, manganese sand filter, shallow bed sand filter, self-cleaning filter, and precision filter. Depending on the user's needs, different filter media and filter cartridges with varying degrees of precision can be selected. When subjected to a certain pressure, this system can efficiently remove suspended solids, organic matter, colloidal particles, and other impurities from turbid water. Additionally, it can eliminate odors and colors, ultimately achieving high-efficiency filtration and purification of water quality.

Industries such as power, electronics, beverages, tap water treatment, petroleum, chemicals, metallurgy, textiles, papermaking, food, swimming pools, municipal engineering, and other processes involving industrial water, domestic water, circulating water, and wastewater treatment widely use this filtration equipment.

Filtration System

The filtration system consists of several filters including:

  • Quartz sand filter
  • Activated carbon filter
  • Manganese sand filter
  • Shallow bed sand filter
  • Self-cleaning filter
  • Precision filter

Different filter media and cartridges are available to suit user's requirements. Under certain pressure, the system can effectively remove suspended solids, organic matter, colloidal particles, and other impurities from turbid water. It also has the capacity to eliminate odors and colors, ensuring high-efficiency filtration and purification of water quality.

Applications

This filtration equipment finds applications in the following industries:

  • Power
  • Electronics
  • Beverages
  • Tap water treatment
  • Petroleum
  • Chemicals
  • Metallurgy
  • Textiles
  • Papermaking
  • Food
  • Swimming Pools
  • Municipal engineering

This equipment serves various processes involving industrial water, domestic water, circulating water, and wastewater treatment.

Inlet pipe diameter(mm) Maximum flow rate(t/h) Drag coefficient Length(mm) Weight(kg) Power(w)
15 1.8 ≤0.5 150 6 15
25 4.9 ≤0.5 500 10 15
40 12 ≤0.5 500 15 20(40)
50 19 ≤0.5 500 15 20(50)
65 28 ≤0.5 500 15 30(60)
80 50 ≤0.5 500 20 30(60)
100 80 ≤0.5 500 25 50(80)
125 125 ≤0.5 600 35 60(100)
150 180 ≤0.5 600 48 80(120)
200 320 ≤0.5 600 60 100(180)
250 490 ≤0.5 700 78 120(200)
300 710 ≤0.5 700 90 150(240)
350 970 ≤0.5 800 125 200(280)
400 1260 ≤0.5 800 160 250(320)
450 1600 ≤0.5 900 200 300(360)
500 1970 ≤0.5 1000 230 300(400)
600 2850 ≤0.5 1000 265 350
700 3880 ≤0.5 1200 395 450
800 5060 ≤0.5 1200 330 500
900 6410 ≤0.5 1200 380 550



Features:

Pre-treatment is a crucial process in producing various types of water, including purified water, boiler feedwater, industrial process water, and drinking water. Without adequate pre-treatment, these waters may contain impurities, such as solids, dissolved minerals, and organic matter, that can affect their quality and performance.

Purified water, for instance, requires pre-treatment to remove impurities and contaminants, such as bacteria, viruses, and particles, that can compromise its purity and safety. Pre-treatment may involve filtration, reverse osmosis, and other processes to ensure the water meets strict quality standards.

Boiler feedwater, which is used in industrial boilers to generate steam, also requires pre-treatment to remove impurities and prevent corrosion and scaling. Without pre-treatment, feedwater can cause damage to boilers and reduce their efficiency, resulting in increased energy and maintenance costs.

Industrial process water, which is used in various manufacturing and production processes, also needs proper pre-treatment to achieve the desired quality and performance. Pre-treatment may involve filtration, sedimentation, disinfection, and other processes to remove impurities and contaminants that can affect the process and end-product quality.

Finally, pre-treatment is also essential for producing safe and potable drinking water. Pre-treatment may include sedimentation, coagulation, flocculation, disinfection, and other processes to remove contaminants, such as bacteria, viruses, and chemicals, and improve the water's taste, odor, and clarity.



Technical Parameters:

Efficient filtration: On-site filtration requirements can be met by selecting different filter media to effectively remove impurities such as suspended solids, organic matter, colloidal particles, microorganisms, and improve water quality.



Biological purification: The purification effect is enhanced by further degradation of organic matter and harmful substances in water.



Backwash regeneration: The filtering performance of quartz sand can be restored through the backwashing and regeneration process, allowing for continuous water purification.



Space-saving: A compact structure and small footprint effectively save space.



Easy installation: Simple operation and easy installation make it possible to directly connect the inlet and outlet water pipes for immediate use. Long service life helps to reduce operating costs.



Strong adaptability: This system is suitable for different water qualities and water quantities, exhibiting good adaptability.



Applications:

There are a variety of applications for industrial water filtration, including the protection of nozzles and heat exchange station water in various industrial processes.

Industrial circulating water can also benefit from filtration in industries such as steel, metallurgy, papermaking, power generation, and more. Other uses for filtration include petrochemicals, food processing, and air conditioning systems.

Filtration is also important for raw water treatment, whether it comes from surface water, rivers, lakes, or even seawater.

Water filtration can also be utilized for irrigation in agricultural fields, parks, municipal water supplies, and golf courses.

For additional water filtration needs, aquaculture operations, swimming pools, and water parks can all benefit from proper filtration solutions.

The benefits of filtration are wide-ranging, as it is suitable for various industries such as power, electronics, beverages, tap water treatment, petroleum, chemicals, metallurgy, textiles, papermaking, food processing, swimming pools, and municipal engineering. This includes industrial water, domestic water, circulating water, and wastewater treatment.
