Precision Water Industrial Sand Filter Filtration System With Quartz Sand / Activated Carbon

Place of Origin Tai'an, Shandong
Brand Name Tonglida
Certification ISO9001 Quality System Certification
Model Number 1T/H-100T/H
Minimum Order Quantity 1 unit
Delivery Time As per requirements

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Features Pre-treatment For Producing Purified Water, Boiler Feedwater, Industrial Process Water, And Drinking Water. Product Information Quartz Sand Filtration, Activated Carbon Filtration, Manganese Sand Filter, Shallow Bed Sand Filtration, Self-cleaning Filtration, Precision Filtration
Material Stainless Steel, Carbon Steel, Fiberglass Purpose Production Of Purified Water, Boiler Feedwater, Industrial Process Water, And Drinking Water Filtration System
Brand Tonglida
High Light

industrial quartz sand filter

,

quartz sand industrial sand filter

,

activated carbon quartz sand filter
Leave a Message
Product Description





Product Description:

The filtration system is an essential tool for those looking to maintain high-quality water. This system consists of several filters, including a quartz sand filter, activated carbon filter, manganese sand filter, shallow bed sand filter, self-cleaning filter, and precision filter. The system can be tailored to fit the user’s requirements, having different filter media and cartridges with various precision degrees.

Water is effectively purified by the system under certain pressure. It removes suspended solids, organic matter, colloidal particles, and other impurities from turbid water. Further, the system plays a vital role in the elimination of odors and colors from the contaminated water.

The filtration equipment is used in various industries such as power generation, electronics, beverages, tap water treatment, petroleum, chemicals, metallurgy, textiles, papermaking, food, swimming pools, municipal engineering, and other processes involving industrial water, domestic water, circulating water, and wastewater treatment.

Model number Flow rate Inlet and outlet diameter Drain diameter Tank diameter Equipment height Motor power
(m³/h) (mm) (mm)
DN40 18 DN40 DN25 219 700
DN50 20 DN50 DN25 219 700 0.18
DN65 30 DN65 DN25 273 1300 0.18
DN80 40 DN80 DN25 273 850 0.18
DN100 60 DN100 DN50 273 936 0.18
DN125 100 DN125 DN50 325 1018 0.37
DN150 150 DN150 DN50 325 111 0.37
DN200 250 DN200 DN50 426 1427 0.37
DN250 400 DN250 DN50 426 1685 0.37
DN300 500 DN300 DN50 530 2100 0.55
DN350 750 DN350 DN80 630 2085 0.55
DN400 1000 DN400 DN80 600 2360 0.55
DN450 1200 DN450 DN100 600 2632
DN500 1500 DN500 DN100 700 2919
DN600 2100 DN600 DN100 800 3510
DN700 3000 DN700 DN200 900 4100
DN800 3800 DN80   1200



Features:

Pre-treatment is a necessary step for the production of a variety of waters, including purified water, boiler feedwater, industrial process water, and drinking water.

This step involves removing any impurities and contaminants from the water source before it undergoes further treatment processes. The pre-treatment process may include physical, chemical, or biological methods depending on the specific water treatment needs.

Ensuring proper pre-treatment helps to protect the downstream equipment from damage and maintain the quality and purity of the water produced. It also ensures that drinking water meets the safety and health standards set by regulatory agencies.

Therefore, pre-treatment is an essential component of water treatment processes that cannot be overlooked.



Technical Parameters:

Efficient Filtration

Meeting on-site filtration requirements allows for selection of different filter media, which effectively removes impurities such as suspended solids, organic matter, colloidal particles, microorganisms, and improves water quality.


Biological Purification

Enhancing the purification effect through the further degradation of organic matter and harmful substances in water.


Backwash Regeneration

Restoration of the filtering performance of quartz sand through the backwashing and regeneration process enables continuous water purification.


Space-saving

The compact structure and small footprint effectively save space.


Easy Installation

Simple operation and easy installation make it possible to directly connect to the inlet and outlet water pipes for immediate use. Also, it has a long service life, which helps reduce operating costs.


Strong Adaptability

With the ability to be suitable for different water qualities and quantities, it exhibits good adaptability.



Applications:

Importance of Water Filtration in Various Industries

Industrial process water requires filtration to protect nozzles and heat exchange stations. Filtration is essential in circulating water used in industries, including steel, metallurgy, papermaking, heat exchangers, power generation, petrochemicals, food, and air conditioning systems.

Raw water treatment also requires filtration, which includes surface water, rivers, lakes, and seawater. Filtration is also necessary for irrigation in agricultural fields, parks, municipal water supplies, and golf courses.

Filtration is also crucial in ensuring the quality of water in aquaculture, swimming pools, and water parks. This process is suitable for various industries, such as power, electronics, beverages, tap water treatment, petroleum, chemicals, metallurgy, textiles, papermaking, food, swimming pools, and municipal engineering. It involves industrial water, domestic water, circulating water, and wastewater treatment.

All these industries rely on effective filtration methods to ensure the quality of water used in their operations. Choose the appropriate filtration system for your industry and ensure clean and safe water for your needs.
